Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
PRIMO
Suspension Fork
3T Fango
Drivetrain
Rear Derailleur
SRAM Rival 1 long cage
Shift Levers
SRAM Rival1 Hydraulic DoubleTap
Cassette
11-speed SRAM Rival 11-42T
Crank
FSA Omega BB386EVO or SRAM Rival depending on availability, 42T chainring ( XXS: 165mm - 51: 170mm - 54&56: 172,5mm - 58&61: 175mm)
Bottom Bracket
BB86/BB92, press-fit
Wheels
Rims
Fulcrum Rapid Red 900, 700c, tubeless ready (upgrade to 3T Discus 45|40, 45|32, Plus i28 possible)
Tires
Pirelli Cinturato Gravel M 700c
Brakes
Brakes
SRAM Rival Flat Mount Hydraulic Disc w/ SRAM 160mm
Cockpit
Stem
APTO STEALTH (S:80mm -M:90mm - L: 100mm - XL:110mm)
Handlebar
3T Superergo Pro bar (S: 40cm - M&L: 42cm - XL: 44cm)
Headset
Sealed cartridge 1.125” - 1.5”
Seat
Saddle
Selle Italia Model X Superflow
Seatpost
3T Exploro seatpost for Ritchey clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.413 mm | 1.444 mm | 1.474 mm | 1.502 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 591 mm | 598 mm | 606 mm | 627 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 67 mm | 58 mm | 58 mm |
| Stack | 517 mm | 546 mm | 575 mm | 604 mm |
| Reach | 366 mm | 378 mm | 390 mm | 402 mm |
| Top Tube Length | 529 mm | 550 mm | 571 mm | 592 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 463 mm | 490 mm | 518 mm | 545 mm |
| Head Tube Angle | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 101 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 996 mm | 1003 mm | 1011 mm | 1032 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 168 cm | 178 cm | 188 cm |
