3T STRADA ITALIA DURA-ACE Di2 2X12 ZIPP 353 NSW 2024
2024 Road
Estimate price |
16,221$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
157cm - 170cm
54cm
168cm - 180cm
56cm
178cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
3T’s in-house filament-winding using a combination of high-strength/high-stiffness fibers, combined with RTM resin injection. Made in Italy
Suspension Fork
3T Fundi Integrale II
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 RD-R9250 12s
Front Derailleur
Shimano Dura-Ace Di2 FD-R9250 12s
Shift Levers
Shimano Dura-Ace Di2 ST-R9270 12s
Cassette
Shimano CS-R9200-12 11-34
Crank
Shimano Dura-Ace FC-R9200-P (with Power Meter) 50/34 12s (51: 170mm - 54&56: 172,5mm - 58&61: 175mm)
Wheels
Rims
Zipp 353 NSW
Tires
Vittoria Corsa Pro TLR 700x30
Brakes
Brakes
Shimano BR-R9270 W/ Shimano RT CL900 160mm rotor
Cockpit
Stem
3T More (K-Edge GPS mount included) - (48: 80mm - 51: 90mm - 54:100mm - 56: 110mm - 58: 120mm )
Handlebar
3T Aeroflux Integrale LTD ( 51: 40cm - 54&56: 42cm - 58: 44cm)
Headset
3T MinMax Integrale IS42/34 | IS47/38(36deg)
Seat
Saddle
Selle Italia SLR Boost Superflow Kit Carbon or San Marco Superleggera depending on availability
Seatpost
3T Strada Italia seatpost for Ritchey clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.458 mm | 1.479 mm | 1.5 mm |
| Bottom Bracket Height | 261 mm | 263 mm | 263 mm | 266 mm |
| Front Center | 596 mm | 587 mm | 601 mm | 615 mm |
| Rake | 60 mm | 49 mm | 49 mm | 49 mm |
| Trail | 52 mm | 53 mm | 53 mm | 53 mm |
| Stack | 532 mm | 554 mm | 574 mm | 594 mm |
| Reach | 369 mm | 380 mm | 388 mm | 396 mm |
| Top Tube Length | 537 mm | 555 mm | 569 mm | 583 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 496 mm | 520 mm | 537 mm | 555 mm |
| Head Tube Angle | 71 ° | 72.7 ° | 72.7 ° | 72.7 ° |
| Head Tube Length | 143 mm | 159 mm | 179 mm | 203 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 991 mm | 983 mm | 997 mm | 1013 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 168 cm | 178 cm | cm |
| Rider Max Height | 170 cm | 180 cm | 191 cm | cm |
