Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque high mod carbon fiber frame. Weight 850 g. Sizes: XS-S-M-L-XL
Drivetrain
Bottom Bracket
Bottom bracket BB86 (86,5x41). Max tire size 700x32
Wheels
Tires
Bottom bracket BB86 (86,5x41). Max tire size 700x32
Brakes
Brakes
Full integrated cable routing. Flat mounts disc brake
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.346 mm | 1.362 mm | 1.397 mm | 1.418 mm | 1.448 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 510 mm | 523 mm | 542 mm | 563 mm | 588 mm |
| Reach | 379 mm | 384 mm | 388 mm | 397 mm | 406 mm |
| Top Tube Length | 515 mm | 536 mm | 548 mm | 565 mm | 587 mm |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
