Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque high mod carbon fiber frame 1.100gr. Monocoque carbon fork 480 gr. Sizes: S-M-L-XL-XXL
Suspension Fork
Monocoque high mod carbon fiber frame 1.100gr. Monocoque carbon fork 480 gr. Sizes: S-M-L-XL-XXL
Drivetrain
Bottom Bracket
Bottom bracket BSA threaded. Seat tube ID 27,2 mm
Wheels
Tires
Max tire size 700x40
Brakes
Brakes
Flat mounts disc brake
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.521 mm | 1.514 mm | 1.496 mm | 1.485 mm | 1.483 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 540 mm | 554 mm | 570 mm | 582 mm | 596 mm |
| Reach | 355 mm | 366 mm | 381 mm | 392 mm | 402 mm |
| Top Tube Length | 515 mm | 535 mm | 556 mm | 575 mm | 595 mm |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm | 175 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
