Allied ABLE SRAM Force XPLR AXS 2025
2025 Road
Estimate price |
8,300$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Force, Force XPLR eTap -
Suspension Rigid -
Drivetrain 1 × 13 Electronic -
Brakes SRAM Force Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
ALLIED ABLE FK09
Drivetrain
Rear Derailleur
SRAM Force XPLR AXS E1
Shift Levers
SRAM Force AXS E1 HRD
Cassette
SRAM Force XPLR XG-1371 13spd 10-46
Crank
SRAM Force XPLR E1 40T
Bottom Bracket
SRAM DUB BSA
Chain
SRAM Force E1 Flattop
Wheels
Rims
Industry Nine 1/1 Ultralite Carbon Gravel
Tires
Continental Race King Protection 29x2.2
Brakes
Brakes
SRAM Force AXS HRD
Cockpit
Stem
ALLIED ST03
Handlebar
FSA K-Wing AGX Carbon Handlebar
Seat
Saddle
Selle Italia Model X
Seatpost
ALLIED SP02
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.385 mm | 1.405 mm | 1.438 mm | 1.451 mm | 1.482 mm |
| Front Center | 611 mm | 622 mm | 633 mm | 651 mm | 663 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Stack | 540 mm | 555 mm | 575 mm | 595 mm | 615 mm |
| Reach | 390 mm | 395 mm | 400 mm | 410 mm | 415 mm |
| Top Tube Length | 534 mm | 554 mm | 564 mm | 580 mm | 591 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 460 mm | 500 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 97 mm | 113 mm | 135 mm | 156 mm | 177 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1039 mm | 1049 mm | 1061 mm | 1078 mm | 1090 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 752 mm | 787 mm | 812 mm | 832 mm | 852 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
