Allied ABLE SRAM RED XPLR AXS 2025
2025 Road
Estimate price |
11,500$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset RED XPLR eTap, RED AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes SRAM RED Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
ALLIED ABLE FK09
Drivetrain
Rear Derailleur
SRAM RED XPLR AXS
Front Derailleur
N/A
Shift Levers
SRAM RED AXS HRD E1
Cassette
SRAM RED XPLR XG-1391 10-46t
Crank
SRAM RED XPLR AXS Power Meter 42t
Bottom Bracket
SRAM DUB BSA
Chain
SRAM RED E1
Wheels
Rims
Industry Nine Solix SL - AR40c
Tires
Continental Race King Protection 29x2.2
Brakes
Brakes
SRAM RED AXS HRD E1
Cockpit
Stem
ALLIED ST03
Handlebar
ENVE SES AR In-Route
Seat
Saddle
Selle Italia SLR Boost Kit Carbonio
Seatpost
ALLIED SPO2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.385 mm | 1.405 mm | 1.438 mm | 1.451 mm | 1.482 mm |
| Front Center | 611 mm | 622 mm | 633 mm | 651 mm | 663 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Stack | 540 mm | 555 mm | 575 mm | 595 mm | 615 mm |
| Reach | 390 mm | 395 mm | 400 mm | 410 mm | 415 mm |
| Top Tube Length | 534 mm | 554 mm | 564 mm | 580 mm | 591 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 460 mm | 500 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 97 mm | 113 mm | 135 mm | 156 mm | 177 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1039 mm | 1049 mm | 1061 mm | 1078 mm | 1090 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 752 mm | 787 mm | 812 mm | 832 mm | 852 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
