Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Belt Drive, IGH -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted Aluminum
Suspension Fork
Double Butted Aluminum
Drivetrain
Shift Levers
Shimano Alfine 8
Crank
Gates Carbon X-Drive (46T)
Bottom Bracket
Real Speed Oversized External Cups
Chain
Gates Carbon Belt
Wheels
Rims
Shimano M-475
Tires
Kenda Kwick-Trax (700 x 38c)
Brakes
Brakes
Shimano
Cockpit
Stem
Alloy 31.6
Handlebar
Alloy Flat Bar
Headset
FSA 1-1/8”
Seat
Saddle
Aquila
Seatpost
FSA SL-K Carbon 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 44cm | 48cm | 52cm | 55cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 0.73 mm | 0.72 mm | 0.71 mm | 0.68 mm | 0.67 mm |
| Bottom Bracket Height | 290 mm | 290 mm | 290 mm | 290 mm | 290 mm |
| Front Center | 622 mm | 623 mm | 626 mm | 626 mm | 636 mm |
| Rake | -34 mm | -41 mm | -47 mm | -64 mm | -74 mm |
| Trail | 167 mm | 167 mm | 170 mm | 184 mm | 191 mm |
| Stack | 390 mm | 396 mm | 400 mm | 397.7 mm | 406 mm |
| Reach | 536 mm | 549 mm | 560 mm | 581.3 mm | 602 mm |
| Top Tube Length | 548 mm | 558 mm | 570 mm | 580 mm | 595 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm | 520 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 135 mm | 145 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1078 mm | 1079 mm | 1081 mm | 1082 mm | 1092 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 734 mm | 750 mm | 774 mm | 802 mm | 827 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
B-Drive belongs to the Aquila B Drive model. Aquila launched 3 bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Aquila released this model in 2021, its price was 1113$. Comparing this to the average Hybrid bike price, we see that the price is 98.04% more expensive.
Overview of components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the B-Drive bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
