Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Pignon 16T
Crank
Driveline TK14 170mm
Bottom Bracket
Driveline (BSA - English)
Chain
KMC Z510HX
Wheels
Rims
Aclass Solo
Tires
Vittoria Rubino Slick II 700x23
Brakes
Brakes
N/A
Brake Levers
N/A
Cockpit
Stem
FSA OS-168 alu
Handlebar
FSA Omega Compact Alliage
Headset
FSA Orbit IS2 1" 1/8
Seat
Saddle
Prologo Zero Tri PAS (STN)
Seatpost
FSA SL-280 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.22 mm | 1.27 mm | 1.3 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 291 mm | 291 mm |
| Front Center | 554 mm | 558 mm | 569 mm | 584 mm |
| Rake | 38 mm | 37 mm | 37 mm | 38 mm |
| Trail | 57 mm | 55 mm | 55 mm | 54 mm |
| Stack | 465 mm | 475 mm | 499 mm | 523 mm |
| Reach | 383 mm | 389 mm | 393 mm | 402 mm |
| Top Tube Length | 498 mm | 518 mm | 533 mm | 553 mm |
| Seat Tube Angle | 76.5 ° | 75 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 410 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 74 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Head Tube Length | 91 mm | 100 mm | 125 mm | 150 mm |
| Chainstay Length | 366 mm | 366 mm | 366 mm | 366 mm |
| Wheelbase | 915 mm | 919 mm | 930 mm | 946 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 716 mm | 726 mm | 750 mm | 774 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Electron is part of the Argon18 Electron model. 8 bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Track bikes
Our math shows that the average cost of a dependable Track bike is 1503$. However, even though the average price of a Track bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Argon 18 Electron price was 1499$. Comparing this to the average Track bike price, we see that the price is 0.27% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Electron model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Sizes
Electron comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
