Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Miche -
Suspension Rigid -
Drivetrain Single Speed
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Cassette
Miche Pistard 15T
Crank
Miche Pistard Air 50T
Bottom Bracket
Miche EvoMax BB
Chain
KMC Chain, Z510HX
Wheels
Rims
Miche Pistard
Tires
Vittoria Zaffiro V 700x25
Cockpit
Handlebar
Prologo Plaintouch black
Seat
Saddle
Kappa RS saddle
Seatpost
FSA Gossamer SB20 Seat Post (27.2mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.244 mm | 1.266 mm | 1.272 mm | 1.277 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 556 mm | 561 mm | 576 mm | 585 mm |
| Rake | 37 mm | 37 mm | 38 mm | 34 mm |
| Trail | 58 mm | 55 mm | 54 mm | 58 mm |
| Stack | 485 mm | 500 mm | 515 mm | 530 mm |
| Reach | 390 mm | 395 mm | 405 mm | 415 mm |
| Top Tube Length | 510 mm | 530 mm | 550 mm | 570 mm |
| Seat Tube Angle | 76.5 ° | 75 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 410 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 74 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Head Tube Length | 85 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 375 mm | 375 mm | 375 mm | 375 mm |
| Wheelbase | 925 mm | 930 mm | 945 mm | 955 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 740 mm | 755 mm | 770 mm | 785 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
