Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Marzocchi Bomber Z1
-
Groupset Truvativ Descendant -
Suspension Full -
Drivetrain Single Speed -
Brakes TRP Slate EVO Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari 801 27.5", 6061-T6 Premium Alloy, Fully Butted Tubing, Tapered Head Tube, BSA 73mm BB Shell, Boost 148 Thru-Axle Sliding Dropouts, Single Speed or Geared
Suspension Fork
Marzocchi Bomber Z1 Air, 27.5", 20x110, 100mm, Tapered
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Joy Tech Single Speed 16T
Crank
SRAM Descendant 6k, 165mm Alloy
Bottom Bracket
SRAM Dub BSA 73 MTB
Chain
KMC Z1 Wide Single Speed
Pedals
Available Separately
Wheels
Front Hub
F: Sun Ringle SRC, 20x110, R: Sun Ringle SRC 12x148, HG
Rear Hub
F: Sun Ringle SRC, 20x110, R: Sun Ringle SRC 12x148, HG
Rims
Sun Ringle Duroc SD37, 27.5"
Spokes
Wheelsmith DB14 J-Bend
Tires
Kenda Booster Pro SCT 120tpi, 27.5x2.4
Brakes
Brakes
F: N/A, R: TRP Slate EVO HD-M807, 2.3 160mm rotor
Cockpit
Stem
Ari DJ 35 Alloy
Handlebar
Ari DJ 35, width 760mm, 50mm rise, 9° back sweep, 5° Up sweep, bar-customized sizing through 23-Point Custom Setup
Headset
FSA No.57E
Seat
Saddle
WTB Solano Medium Steel
Seatpost
Ari Alloy DJ, 27.2x200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 26" | 27.5 |
|---|---|---|
| Stack Reach Ratio | 1.388 mm | 1.354 mm |
| Bottom Bracket Height | 318 mm | 313 mm |
| Stack | 569 mm | 595.7 mm |
| Reach | 410 mm | 440 mm |
| Top Tube Length | 584 mm | 600 mm |
| Seat Tube Angle | 73 ° | 75 ° |
| Seat Tube Length | 300 mm | 320 mm |
| Head Tube Angle | 69 ° | 68 ° |
| Head Tube Length | 120 mm | 120 mm |
| Chainstay Length | 385 mm | 395 mm |
| Bottom Bracket Drop | 22 mm | 42 mm |
| Wheels | 27" | 27" |
