Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 135mm -
Fork DVO Diamond
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Delano Peak, CleanCast Carbon TetraLink Full Suspension, 135mm travel. Internal Future-Proof cable routing on top of Downtube. CleanCatch rattle-proof cable guides. SRAM Universal Derailleur Hanger. 2 Flush-mount bottle cages (M,L,XL)
Suspension Fork
DVO Diamond 36 D1 29 150mm
Rear Shock
DVO Topaz Gen 3 210x50, 25x8mm/30x8mm, Custom Tuned
Drivetrain
Rear Derailleur
Shimano SLX 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano Deore Trigger 12-Speed
Cassette
Shimano Deore Hyperglide+, 10-51t, 12-Speed
Crank
Shimano FC-MT511-1
Bottom Bracket
Shimano Hollowtech, 24mm, BB-MT501 English Thread
Chain
Shimano Deore 12-Speed
Pedals
Available Separately
Wheels
Front Hub
F: Bear Pawls BMB003 Sealed Bearing Disc, 110x15mm thru axle, 32 hole, 6 bolt; R: Bear Pawls BMB004 Sealed Bearing Disc, 148x12mm thru axle, 32 hole, 6 bolt
Rear Hub
F: Bear Pawls BMB003 Sealed Bearing Disc, 110x15mm thru axle, 32 hole, 6 bolt; R: Bear Pawls BMB004 Sealed Bearing Disc, 148x12mm thru axle, 32 hole, 6 bolt
Rims
E-thirteen Sylvan Core Alloy, 32 hole, Disc, Tubeless Ready
Spokes
Stainless, black, with brass nipple
Tires
Maxxis Minion DHF 29x2.5WT, EXO, Tubeless Ready. Aggressor 29x2.5WT, EXO, Tubeless Ready
Brakes
Brakes
TRP Slate EVO, HD-M807 Centerline 180/180 F/R rotors
Cockpit
Stem
Ari Charger CNC 35 stem
Handlebar
Ari Team 35, width 780/800mm, 25mm rise, 9° back sweep, 5° Up sweep, bar-customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Ergon SM10
Seatpost
TranzX JD-YSI05J w/ Travel Adj. 30mm, Dropper- customized sizing through 23-Point Custom Setup
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.419 mm | 1.341 mm | 1.308 mm | 1.284 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 744 mm | 777 mm | 801 mm | 827 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 133 mm | 124 mm | 134 mm | 134 mm |
| Stack | 610 mm | 610 mm | 628 mm | 642 mm |
| Reach | 430 mm | 455 mm | 480 mm | 500 mm |
| Top Tube Length | 560 mm | 593 mm | 613 mm | 637 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 445 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 95 mm | 115 mm | 130 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1176 mm | 1209 mm | 1234 mm | 1260 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 734 mm | 741 mm | 751 mm | 763 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
