Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 135mm -
Fork RockShox Lyrik Ultimate
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Delano Peak, CleanCast Carbon TetraLink Full Suspension, 135mm travel. Internal Future-Proof cable routing on top of Downtube. CleanCatch rattle-proof cable guides. SRAM Universal Derailleur Hanger. 2 Flush-mount bottle cages (M,L,XL)
Suspension Fork
Rockshox Lyrik Ultimate, Charger 3, Buttercups, 29 150mm
Rear Shock
Rockshox Super Deluxe Ultimate, RC2T Hydraulic Bottom Out, 210x50, 25x8mm/30x8mm, Custom Tuned
Drivetrain
Rear Derailleur
Shimano XT 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano XT Trigger 12-Speed
Cassette
Shimano XT Hyperglide+, 10-51t, 12-Speed
Crank
Shimano XT 12-Speed
Bottom Bracket
Shimano MT800 English Thread
Chain
Shimano XT, 12-Speed
Pedals
Available Separately
Wheels
Front Hub
DT Swiss M 1900 Spline, LN 18
Rear Hub
DT Swiss M 1900 Spline, LN 18
Rims
DT Swiss M 1900 Spline, 28 hole, Disc, Tubeless Ready
Spokes
DT Swiss M 1900 Spline
Tires
Maxxis Minion DHF 29x2.5WT, EXO, Tubeless Ready. Aggressor 29x2.5WT, EXO, Tubeless Ready
Brakes
Brakes
Shimano XT M8120 4-piston, 180/180 RT86 Ice-Tech F/R rotors
Cockpit
Stem
Ari Charger CNC 35 stem
Handlebar
Ari Team 35, width 780/800mm, 25mm rise, 9° back sweep, 5° Up sweep, bar-customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Ergon SM10
Seatpost
TranzX JD-YSI05J w/ Travel Adj. 30mm Dropper- customized sizing through 23-Point Custom Setup
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.419 mm | 1.341 mm | 1.308 mm | 1.284 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 744 mm | 777 mm | 801 mm | 827 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 133 mm | 124 mm | 134 mm | 134 mm |
| Stack | 610 mm | 610 mm | 628 mm | 642 mm |
| Reach | 430 mm | 455 mm | 480 mm | 500 mm |
| Top Tube Length | 560 mm | 593 mm | 613 mm | 637 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 445 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 95 mm | 115 mm | 130 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1176 mm | 1209 mm | 1234 mm | 1260 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 734 mm | 741 mm | 751 mm | 763 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
