Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Groupset SLX -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Racing Design Fat King Carbon V3, full carbon construction, 197x12mm rear axle, 100mm english thread BB, tapered headtube, internal cable routing
Suspension Fork
Ari Racing Design Kings Peak Carbon V3, tapered, 150x15mm thru axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX SGS 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano SLX Trigger 12-Speed
Cassette
SLX M7100, 10-51t, 12-speed
Crank
Samox TAM38, for Fat Bike
Bottom Bracket
Samox BSA EB2403BB 100
Chain
Shimano SLX 12-speed
Pedals
Available Separately
Wheels
Front Hub
Sun Ringlé SRC 197x12, 150x15, Microspline
Rear Hub
Sun Ringlé SRC 197x12, 150x15, Microspline
Rims
Sun Ringle Mulefut SL 80mm, 32 hole, 27.5. Carbon Wheel Upgrade Available At Checkout
Spokes
Wheelsmith DB14
Tires
Maxxis Colossus EXO, 27.5x4.5 Tubeless Ready
Brakes
Brakes
Tektro HD-M275 Hydraulic 180/160mm Rotors
Cockpit
Stem
Ari Alloy, 31.8mm (Size varies with 23-point custom setup)
Handlebar
Ari Racing Design Alloy Riser Bar, 31.8mm x 780mm, 25mm Rise (customized sizing through 23-Point Custom Setup)
Headset
FSA integrated sealed cartridge bearing, tapered, No. 57E
Seat
Saddle
WTB Volt Comp
Seatpost
Ari alloy, blast black, 31.6 x 350-400 (based on custom setup), Dropper seatpost available after adding bike to cart
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.391 mm | 1.367 mm | 1.33 mm | 1.296 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm | 325 mm |
| Front Center | 715 mm | 742 mm | 766 mm | 790 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 95 mm | 95 mm |
| Stack | 598 mm | 615 mm | 625 mm | 635 mm |
| Reach | 430 mm | 450 mm | 470 mm | 490 mm |
| Top Tube Length | 590 mm | 614 mm | 637 mm | 660 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 440 mm | 460 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1156 mm | 1184 mm | 1208 mm | 1232 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 700 | 750 mm | 770 mm | 780 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
