Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork DVO Diamond
-
Groupset SLX, Praxis -
Suspension Full -
Motor Fazua 60Nm mid-drive -
Battery Fazua Energy 430Wh FIX -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Nebo Peak Full Suspension, 140mm travel. UDH derailleur hanger.
Suspension Fork
DVO Diamond D1, 29, 150mm travel, Boost 15x110 , 44mm offset, tapered steerer - Grey
Rear Shock
DVO Topaz Gen 3, 210x55, Custom Tuned
Drivetrain
Rear Derailleur
Shimano SLX, SGS, 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano SLX Trigger 12-Speed
Cassette
Shimano CS-M7100-12, 10-51t, 12-Speed
Crank
Praxis EC-6 Etor Spline 160mm
Chain
Shimano SLX 12-Speed
Pedals
Available Separately
Wheels
Front Hub
F: DT Swiss 370, Sealed Bearing Disc, 110x15mm thru axle, 28 hole, 6 bolt; R: DT Swiss 370 Ratchet LN 18 Sealed Bearing Disc, 148x12mm thru axle, 28 hole, 6 bolt, MicroSpline
Rear Hub
F: DT Swiss 370, Sealed Bearing Disc, 110x15mm thru axle, 28 hole, 6 bolt; R: DT Swiss 370 Ratchet LN 18 Sealed Bearing Disc, 148x12mm thru axle, 28 hole, 6 bolt, MicroSpline
Rims
DT Swiss M 1900 Spline, 28 hole, Disc, Tubeless Ready
Spokes
DT Champion Straightpull, black, with DT Swiss Squorx Prohead aluminium nipple
Tires
F: Maxxis Dissector 29x2.4, EXO+, 3C, TR Protection, Tubeless Ready. R: Maxxis Dissector 29x2.4, DoubleDown, 3C, MaxxTerra, TR Protection, Tubeless Ready
Brakes
Brakes
TRP Slate Evo, HD-M807, TRP 2.3mm 180/180 F/R rotors
Cockpit
Stem
Ari Charger CNC 35 stem
Handlebar
Ari Team 35mm bar-customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS56 | ZS56/40
Seat
Saddle
Ergon SM10
Seatpost
TransX JD-YSI05J w/ Travel Adj. Dropper- customized sizing through 23-Point Custom Setup
Motor & Battery
Motor
Fazua Ride 60, 60Nm
Battery
Fazua Energy 430Wh FIX
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.421 mm | 1.354 mm | 1.296 mm | 1.291 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 751 mm | 778 mm | 806 mm | 845 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 126 mm | 126 mm | 126 mm | 126 mm |
| Stack | 611 mm | 615.9 mm | 622.3 mm | 652 mm |
| Reach | 430 mm | 455 mm | 480 mm | 505 mm |
| Top Tube Length | 568.3 mm | 589.9 mm | 612.3 mm | 642.4 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 390 mm | 400 mm | 420 mm | 450 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 105 mm | 113 mm | 145 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1184 mm | 1211 mm | 1239 mm | 1278 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 737 mm | 736 mm | 736 mm | 736 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
