Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset XX Eagle Transmission, Force -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Shafer Gravel Frameset - MonoForm™ CleanCast™ Carbon, 12x142 rear 12x100 front thru axles. UDH derailleur hanger. Max tire clearance 50c.
Suspension Fork
Ari Racing Design Gravel Disc, 12mm thru-axle, Carbon fiber design with Road-Damping Technology, Full carbon construction, carbon tapered steerer tube, 50c tire clearance, 50mm offset, 1 1/8-1.5 taper, internal routing
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM XX Eagle Transmission 1x12
Front Derailleur
N/A
Shift Levers
SRAM Force eTAP AXS 1x12 Hydraulic
Cassette
SRAM XS-1297 XX, 10-52
Crank
SRAM Force, DUB, Wide 1x12, Carbon
Bottom Bracket
SRAM Dub English BSA
Chain
SRAM XX Eagle Transmission Flattop 12-speed
Pedals
Available Separately
Wheels
Front Hub
DT Swiss 350 Ratchet LN 36 SL
Rear Hub
DT Swiss 350 Ratchet LN 36 SL
Rims
DT Swiss GR 1600
Spokes
DT aero comp® wide straightp
Tires
Maxxis Rambler 45c Tan Wall EXO Tubeless Ready
Brakes
Brakes
SRAM Force AXS Hydraulic Disc, SRAM Centerline 160mm Rotors
Cockpit
Stem
Ari 3D forged 31.8mm alloy, 7 degree, 4-bolt bar clamp (customized sizing through 23-Point Custom Setup)
Handlebar
Ari GR Carbon. 31.8 diameter, 80mm reach, 120mm drop,15 degree flare
Headset
FSA SRS 1.5
Seat
Saddle
Selle Italia Model-X
Seatpost
Ari Carbon Dual Bolt, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.388 mm | 1.441 mm | 1.495 mm | 1.512 mm | 1.572 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 614 mm | 629 mm | 646 mm | 660 mm | 671 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Stack | 526 mm | 555.7 mm | 585.4 mm | 604.7 mm | 631 mm |
| Reach | 379 mm | 385.7 mm | 391.5 mm | 400 mm | 401.5 mm |
| Top Tube Length | 515.4 mm | 532.4 mm | 559.3 mm | 579 mm | 594.4 mm |
| Seat Tube Angle | 75.5 ° | 75.2 ° | 74 ° | 73.5 ° | 73.1 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 492 mm | 520 mm |
| Head Tube Angle | 68.9 ° | 68.9 ° | 68.9 ° | 68.9 ° | 68.9 ° |
| Head Tube Length | 93.7 mm | 125.8 mm | 158 mm | 178 mm | 206.1 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1032 mm | 1047 mm | 1064 mm | 1079 mm | 1090 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 77 mm | 77 mm | 77 mm |
| Standover Height | 699 mm | 730 mm | 760 mm | 788 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
