Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 120mm -
Travel Rear 110mm -
Fork RockShox SID
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes TRP Slate EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Signal Peak 3.0 Clean Cast™ Carbon, 110mm of Tetra-Link™ Race Lite suspension travel, internal tube-in-tube cable routing, 12x148mm Full-Mount UDH dropout, threaded BB, 2 bottle cage mounts (all frame sizes)
Suspension Fork
Rockshox SID, 3 Position Remote, RUSH RL, DebonAir+ 120mm travel, 15x110 Axle, tapered steerer
Rear Shock
Rockshox SIDLuxe Select+, 3 Position Remote, 190x45mm, Custom Tuned
Drivetrain
Rear Derailleur
Shimano Deore, 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano Deore Trigger, 12-Speed
Cassette
Shimano Deore, 10-51T, 12-Speed
Crank
Shimano MT510-1 -customized sizing through Ari Custom Setup
Bottom Bracket
Shimano BB-MT501 English Thread
Chain
Shimano Deore, 12-Speed
Pedals
Available Separately
Wheels
Front Hub
F: DT Swiss 370, Disc, 15x110 thru axle, R: DT Swiss 370 Ratchet LN 18, Disc, 12x148 thru axle, MicroSpline
Rear Hub
F: DT Swiss 370, Disc, 15x110 thru axle, R: DT Swiss 370 Ratchet LN 18, Disc, 12x148 thru axle, MicroSpline
Rims
DT Swiss X 1900, 29, 28 hole, disc specific, tubeless ready
Spokes
DT Swiss Champion Straightpull
Tires
Maxxis Rekon Race 29x2.4WT, Maxxspeed, EXO, Tubeless Ready
Brakes
Brakes
TRP Slate EVO, HD-M807, 2.3mm 180/180 F/R rotors
Cockpit
Stem
Ari CNC 31.8 stem
Handlebar
Ari XC 31.8, width 760mm, 0mm rise, 9° back sweep, 0° Up sweep, bar-customized sizing through Ari Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
WTB Silverado 265 Medium Steel
Seatpost
TranzX JD-YSI05J w/ Travel Adj. Dropper- customized sizing through Ari Custom Setup
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.407 mm | 1.364 mm | 1.311 mm | 1.248 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 719 mm | 742 mm | 773 mm | 812 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 115 mm | 115 mm | 114 mm | 115 mm |
| Stack | 597.9 mm | 607.1 mm | 616.3 mm | 630.1 mm |
| Reach | 425 mm | 445 mm | 470 mm | 505 mm |
| Top Tube Length | 574.1 mm | 596.3 mm | 623.6 mm | 662.1 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 420 mm | 450 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1146 mm | 1170 mm | 1200 mm | 1240 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 748 mm | 748 mm | 748 mm | 758 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
