Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 115mm -
Fork RockShox SID Ultimate
-
Groupset X0 Eagle Transmission, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Signal Peak SL CleanCast™ Carbon TetraLink™ Full Suspension, 115mm travel. Internal FutureProof™ cable routing on top of Downtube. CleanCatch™ rattle-proof cable guides. UDH derailleur hanger. ISCG-05 mounts, two hole. 2 flush-mount bottle cages (all frame sizes)
Suspension Fork
Rockshox SID Ultimate 3 Position Remote Adjust, 120mm travel, 15x110 Axle, tapered steerer
Rear Shock
Rockshox SIDLuxe Ultimate 3 Position Remote Adjust, 190x45mm, Custom Tuned
Drivetrain
Rear Derailleur
SRAM X0 Eagle Transmission 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM AXS POD 12-Speed
Cassette
SRAM XS-1295 X0 Eagle, 10-52t, 12-speed
Crank
SRAM X0 Eagle, DUB Wide-customized sizing through 23-Point Custom Setup
Bottom Bracket
SRAM Dub English Thread
Chain
SRAM X0 Eagle Transmission Flattop 12-speed
Pedals
Available Separately
Wheels
Front Hub
ZIPP 1Zero HITOP S
Rear Hub
ZIPP 1Zero HITOP S
Rims
ZIPP 1Zero HITOP S Carbon, 24H disc specific, tubeless ready
Spokes
ZIPP 1Zero HITOP S
Tires
Maxxis Rekon 29x2.4WT, 3C,Maxx Terra, EXO, Tubeless Ready
Brakes
Brakes
SRAM Level Silver Stealth 4-Pistion, HS2 180/180 F/R rotors
Cockpit
Stem
Ari CNC35 stem
Handlebar
Ari Team 35, width 780/800mm, 25mm rise, 9° back sweep, 5° Up sweep, bar-customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Ergon SM10
Seatpost
OneUp V3 Dropper- customized sizing through 23-Point Custom Setup
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.403 mm | 1.366 mm | 1.333 mm | 1.304 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 720 mm | 737 mm | 759 mm | 780 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 606 mm | 612 mm | 621 mm | 630 mm |
| Reach | 432 mm | 448 mm | 466 mm | 483 mm |
| Top Tube Length | 593 mm | 610 mm | 629 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 425 mm | 455 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1148 mm | 1165 mm | 1187 mm | 1208 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 730 mm | 735 mm | 745 mm | 757 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
