Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 115mm -
Fork RockShox SID Ultimate
-
Groupset XX SL Eagle Transmission, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Signal Peak SL CleanCast™ Carbon TetraLink™ Full Suspension, 115mm travel. Internal FutureProof™ cable routing on top of Downtube. CleanCatch™ rattle-proof cable guides. UDH derailleur hanger. ISCG-05 mounts, two hole. 2 flush-mount bottle cages (all frame sizes)
Suspension Fork
Rockshox SID Ultimate 3P Remote Adjust, 120mm travel, 15x110 Axle, tapered steerer
Rear Shock
Rockshox SIDLuxe Ultimate 3 Postion Remote Adjust, 190x45mm, Custom Tuned
Drivetrain
Rear Derailleur
SRAM XX SL Eagle Transmission 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM AXS POD 12-Speed
Cassette
SRAM XS-1299 XX SL Eagle Transmission, 10-52t, 12-speed
Crank
SRAM XX SL Eagle, DUB Wide-customized sizing through 23-Point Custom Setup
Bottom Bracket
SRAM DUB BSA MTB73
Chain
SRAM XX SL Eagle Transmission Flattop 12-speed
Pedals
Available Separately
Wheels
Front Hub
Zipp 1Zero Hitop SW
Rear Hub
Zipp 1Zero Hitop SW
Rims
Zipp 1Zero Hitop SW Carbon 29 Tubeless Ready
Spokes
Zipp 1Zero Hitop SW
Tires
Maxxis Rekon Race 29x2.35, EXO, TR Protection, Tubeless Ready
Brakes
Brakes
SRAM Level Ultimate Stealth 4-Piston, 180/160mm F/R Rotors
Cockpit
Stem
Enve Alloy 31.8
Handlebar
Enve M5 Carbon Mountain Handlebar 31.8x760mm bar. Customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Ergon SM10
Seatpost
Fox Transfer SL Factory Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.403 mm | 1.366 mm | 1.333 mm | 1.304 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 720 mm | 737 mm | 759 mm | 780 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 606 mm | 612 mm | 621 mm | 630 mm |
| Reach | 432 mm | 448 mm | 466 mm | 483 mm |
| Top Tube Length | 593 mm | 610 mm | 629 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 425 mm | 455 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1148 mm | 1165 mm | 1187 mm | 1208 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 730 mm | 735 mm | 745 mm | 757 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
