Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Veyo S Aero Carbon Frame
Suspension Fork
Ari Veyo S Aero Carbon Fork
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 2x11
Cassette
Shimano 105 11/34T 11-Speed
Crank
Shimano 105
Bottom Bracket
Shimano BB86
Chain
Shimano 105 11-Speed
Pedals
Available Separately
Wheels
Front Hub
DT Swiss 370 3-Paw
Rear Hub
DT Swiss 370 3-Paw
Rims
DT Swiss E1800
Spokes
DT aero comp® wide straightp, DT aero® straightpull
Tires
Maxxis High Road 28c Tubeless Ready
Brakes
Brakes
Shimano 105 Hydraulic Road Disc, Rotors: 160mm/160mm
Cockpit
Stem
Ari Alloy
Handlebar
Ari Road Compact Alloy
Headset
FSA SRS 1.5/1.5
Seat
Saddle
Selle Italia Model X
Seatpost
Ari Aero Carbon Dual Bolt
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.387 mm | 1.425 mm | 1.421 mm | 1.436 mm |
| Bottom Bracket Height | 271 mm | 273 mm | 273 mm | 273 mm | 275 mm |
| Front Center | 562 mm | 579 mm | 590 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 60 mm | 57 mm | 57 mm | 54 mm |
| Stack | 510 mm | 530 mm | 557 mm | 570 mm | 590 mm |
| Reach | 368 mm | 382 mm | 391 mm | 401 mm | 411 mm |
| Top Tube Length | 505 mm | 525 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 423 mm | 466 mm | 497 mm | 525 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 98 mm | 119 mm | 146 mm | 159 mm | 180 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 961 mm | 979 mm | 990 mm | 1005 mm | 1016 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 68 mm |
| Standover Height | 716 mm | 748 mm | 777 mm | 798 mm | 822 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
