Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Veyo S Aero Carbon Frame
Suspension Fork
Ari Veyo S Aero Carbon Fork
Drivetrain
Rear Derailleur
SRAM Rival AXS, 12-speed, 36T Max
Front Derailleur
SRAM Rival AXS, Braze-on
Shift Levers
SRAM Rival AXS eTap
Cassette
SRAM XG-1250, 10-36T
Crank
SRAM Rival AXS Left Arm Power Meter, DUB
Bottom Bracket
SRAM DUB, BB86
Chain
SRAM Rival, 12-Speed
Pedals
Available Separately
Wheels
Front Hub
DT Swiss P1800
Rear Hub
DT Swiss P1800
Rims
DT Swiss P1800
Spokes
DT Swiss P1800
Tires
Maxxis High Road 28c, Tubeless Ready
Brakes
Brakes
SRAM Rival Hydraulic Road Disc, Centerline Rotors: 160mm/160mm
Cockpit
Stem
FSA SMR
Handlebar
Ari Road Compact Alloy
Headset
FSA SRS 1.5/1.5
Seat
Saddle
Selle Italia X3 Boost
Seatpost
Ari Aero Carbon, Dual Bolt
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.387 mm | 1.425 mm | 1.421 mm | 1.436 mm |
| Bottom Bracket Height | 271 mm | 273 mm | 273 mm | 273 mm | 275 mm |
| Front Center | 562 mm | 579 mm | 590 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 60 mm | 57 mm | 57 mm | 54 mm |
| Stack | 510 mm | 530 mm | 557 mm | 570 mm | 590 mm |
| Reach | 368 mm | 382 mm | 391 mm | 401 mm | 411 mm |
| Top Tube Length | 505 mm | 525 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 423 mm | 466 mm | 497 mm | 525 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 98 mm | 119 mm | 146 mm | 159 mm | 180 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 961 mm | 979 mm | 990 mm | 1005 mm | 1016 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 68 mm |
| Standover Height | 716 mm | 748 mm | 777 mm | 798 mm | 822 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
