Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ari Veyo SL Aero Carbon Frame
Suspension Fork
Ari Veyo SL Aero Carbon Fork
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 R9250
Front Derailleur
Shimano Dura-Ace Di2 R9250
Shift Levers
Shimano Dura-Ace Di2 R9270 2x12
Cassette
Shimano Dura-Ace, 11-30t 12-Speed
Crank
Shimano Dura-Ace R9200
Bottom Bracket
Shimano Dura-Ace
Chain
Shimano Dura-Ace 12-Speed
Pedals
Available Separately
Wheels
Front Hub
Zipp ZR1 142x12/100x12
Rear Hub
Zipp ZR1 142x12/100x12
Rims
Zipp 404 Firecrest Carbon
Spokes
Sapim CX-Ray
Tires
Maxxis High Road 28c Tubeless Ready
Brakes
Brakes
Shimano Dura-Ace Di2 Hydraulic Road Disc, Rotors: 160mm/160mm
Cockpit
Stem
FSA SMR Alloy
Handlebar
Vision Metron Aero Compact Handlebar Carbon Integrated
Headset
FSA ACR NS 1.5/1.5
Seat
Saddle
Ergon SR Pro Titanium
Seatpost
Ari Aero Carbon Dual Bolt
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.387 mm | 1.425 mm | 1.421 mm | 1.436 mm |
| Bottom Bracket Height | 271 mm | 273 mm | 273 mm | 273 mm | 275 mm |
| Front Center | 562 mm | 579 mm | 590 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 60 mm | 57 mm | 57 mm | 54 mm |
| Stack | 510 mm | 530 mm | 557 mm | 570 mm | 590 mm |
| Reach | 368 mm | 382 mm | 391 mm | 401 mm | 411 mm |
| Top Tube Length | 505 mm | 525 mm | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 423 mm | 466 mm | 497 mm | 525 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 98 mm | 119 mm | 146 mm | 159 mm | 180 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 961 mm | 979 mm | 990 mm | 1005 mm | 1016 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 68 mm |
| Standover Height | 716 mm | 748 mm | 777 mm | 798 mm | 822 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
