Atherton S.170.2 2024

Bike details

Overview

Key information split into simple groups.

Bike summary

Category
- Mountain
- |
- Enduro
Frame Aluminum
Travel Front 180mm
Fork Fox Performance Float 38
Groupset GX Eagle
Suspension Full
Drivetrain 1 × 12
Brakes Hydraulic Disc

Parts list

Components

Main components, grouped by system.

Bike components

Frame

Atherton S.170

Suspension Fork

Fox 38 Performance 180mm

Drivetrain

Rear Derailleur

SRAM GX Eagle

Shift Levers

SRAM GX Eagle

Cassette

SRAM GX Eagle 10-50

Crank

SRAM GX Eagle 165mm 32t

Bottom Bracket

SRAM DUB 73mm Threaded

Chain

SRAM GX Eagle

Wheels

Rims

Stans Flow S2 e-Sync (29” | 27.5”)

Tires

Continental Krypototal Enduro 2.4

Brakes

Hayes Dominion A4

Cockpit

Stem

FSA Gradient 35x35

Grips

ODI Flow

Headset

FSA Trail

Seat

Saddle

SHOCK, Prologo Nembo 145mm Cromo, Fox Float X2 Performance

Fit data

Geometry

Numbers for sizing and ride feel.

Size	SIZE 01	SIZE 02	SIZE 03	SIZE 04	SIZE 05	SIZE 06	SIZE 07	SIZE 08	SIZE 09	10"	11"	12"
Stack Reach Ratio	1.543 mm	1.506 mm	1.471 mm	1.437 mm	1.445 mm	1.413 mm	1.383 mm	1.354 mm	1.355 mm	1.327 mm	1.301 mm	1.276 mm
Bottom Bracket Height	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm	343 mm
Front Center	755 mm	765 mm	775 mm	785 mm	799 mm	809 mm	819 mm	829 mm	840 mm	850 mm	860 mm	870 mm
Rake	46 mm	46 mm	46 mm	46 mm	42 mm	42 mm	42 mm	42 mm	36 mm	36 mm	36 mm	36 mm
Trail	122 mm	122 mm	122 mm	122 mm	127 mm	127 mm	127 mm	127 mm	133 mm	133 mm	133 mm	133 mm
Stack	625 mm	625 mm	625 mm	625 mm	643 mm	643 mm	643 mm	643 mm	657 mm	657 mm	657 mm	657 mm
Reach	405 mm	415 mm	425 mm	435 mm	445 mm	455 mm	465 mm	475 mm	485 mm	495 mm	505 mm	515 mm
Seat Tube Angle	77 °	77 °	77 °	77 °	78 °	78 °	78 °	78 °	79 °	79 °	79 °	79 °
Seat Tube Length	395 mm	395 mm	395 mm	395 mm	420 mm	420 mm	420 mm	440 mm	440 mm	460 mm	460 mm	480 mm
Head Tube Angle	64 °	64 °	64 °	64 °	64 °	64 °	64 °	64 °	64 °	64 °	64 °	64 °
Head Tube Length	90 mm	90 mm	90 mm	90 mm	110 mm	110 mm	110 mm	110 mm	125 mm	125 mm	125 mm	125 mm
Chainstay Length	430 mm	430 mm	430 mm	430 mm	435 mm	435 mm	435 mm	435 mm	440 mm	440 mm	440 mm	440 mm
Wheelbase	1185 mm	1195 mm	1205 mm	1215 mm	1234 mm	1244 mm	1254 mm	1264 mm	1280 mm	1290 mm	1300 mm	1310 mm
Bottom Bracket Drop	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm	12 mm
Standover Height	716 mm	716 mm	716 mm	716 mm	728 mm	728 mm	728 mm	728 mm	728 mm	743 mm	743 mm	743 mm
Wheels	27"	27"	27"	27"	27"	27"	27"	27"	27"	27"	27"	27"
