Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork RST CAPA
-
Groupset Acera -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Tektro Mechanical Disc
Sizing
Recommended size guide.
13"
130cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 26"
Suspension Fork
RST Capa T 26 (80 mm)
Drivetrain
Rear Derailleur
SHIMANO Acera
Shift Levers
SHIMANO Acera (8)
Cassette
SHIMANO CS-HG400-8, 11-40 (8)
Crank
PROWHEEL, 32 teeth, 152 mm cranks
Chain
KMC Z8.3
Pedals
plastic
Wheels
Front Hub
QUANDO Disc, 32 holes
Rear Hub
QUANDO Disc, 32 holes
Rims
alloy, 32 holes
Spokes
black steel
Tires
AUTHOR Speed Master, 26" × 2.00"
Brakes
Brakes
TEKTRO, disc mechanical (6" rotors)
Cockpit
Stem
alloy
Handlebar
steel, 20 mm 620 mm
Seat
Saddle
AUTHOR
Seatpost
alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" |
|---|---|
| Stack Reach Ratio | 1.518 mm |
| Front Center | 599 mm |
| Rake | 38 mm |
| Stack | 551 mm |
| Reach | 363 mm |
| Top Tube Length | 526 mm |
| Seat Tube Angle | 73.5 ° |
| Seat Tube Length | 343 mm |
| Head Tube Angle | 69.5 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 425 mm |
| Wheelbase | 1022 mm |
| Bottom Bracket Drop | 30 mm |
| Wheels | 26" |
| Rider Min Height | 130 cm |
| Rider Max Height | 150 cm |
