Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Travel Front 60mm -
Fork RST VOGUE
-
Groupset Deore, Alivio -
Suspension Hardtail -
Brakes Rim
Sizing
Recommended size guide.
16"
150cm - 166cm
18"
164cm - 176cm
20"
174cm - 186cm
22"
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR C-carbon monocoque 700c
Suspension Fork
RST Vogue Air air, lock out, 1.5" tapered steerer (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Front Derailleur
SHIMANO Alivio (31.8)
Shift Levers
SHIMANO Alivio (27)
Cassette
SHIMANO HG-50-9 11-34 (9)
Crank
SUNTOUR NCX-T418 48-36-26 teeth 170 / 175 mm cranks
Chain
SHIMANO HG-53
Pedals
AUTHOR alloy
Wheels
Front Hub
SHIMANO Deore 32 holes
Rear Hub
SHIMANO Deore 32 holes
Rims
AUTHOR Argon Cross black 32 holes
Spokes
black stainless steel 2.0 mm
Tires
AUTHOR PANARACER Silk Road Cross Kevlar 700 x 38c
Brakes
Brakes
TEKTRO M530
Cockpit
Stem
AUTHOR
Handlebar
AUTHOR 20 mm 620 / 640 mm
Grips
AUTHOR Luxus ErgoGrip
Seat
Saddle
AUTHOR Summit
Seatpost
AUTHOR (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 611 mm | 618 mm | 641 mm | 664 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 546 mm | 553 mm | 576 mm | 598 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 461 mm | 512 mm | 563 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1040 mm | 1047 mm | 1070 mm | 1093 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 198 cm |
Model Overview
Avion belongs to the Author Avion model. Author launched 5 bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Hybrid bikes average weight
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 11.9 kg (26.23 lbs), the Avion model is much lighter than average. To sum up, it’s 16.39% lighter than the average weight of Hybrid bikes.
Avion components
Fork
Author Avion 2014 bike is equipped with the RST VOGUE fork, and has 60mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Avion 2014 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Avion has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 4 sizes. They vary from 150 cm – 198 cm (4.92 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
