Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Travel Front 60mm -
Fork RST VOGUE
-
Groupset Deore, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
16"
150cm - 166cm
18"
164cm - 176cm
20"
174cm - 186cm
22"
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR C carbon monocoque 700c
Suspension Fork
RST Vogue Air air, lock out 1.5" tapered steerer (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Front Derailleur
SHIMANO Acera (34.9)
Shift Levers
SHIMANO Alivio (27)
Cassette
SHIMANO HG400-9 11-34 (9)
Crank
SUNTOUR NCX-T418 48-36-26 teeth 170 / 175 mm cranks
Chain
SHIMANO HG53
Pedals
AUTHOR oneside clipless
Wheels
Front Hub
AUTHOR 32 holes
Rear Hub
AUTHOR 32 holes
Rims
AUTHOR Argon Cross 32 holes
Spokes
black stainless steel 2.0 mm
Tires
AUTHOR PANARACER Silk Road Cross kevlar 700 x 42c
Brakes
Brakes
TEKTRO M530
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 620 / 640 / 660 mm
Grips
AUTHOR Luxus ErgoGrip
Seat
Saddle
AUTHOR Summit
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 611 mm | 618 mm | 641 mm | 664 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 546 mm | 553 mm | 576 mm | 598 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 461 mm | 512 mm | 563 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1040 mm | 1047 mm | 1070 mm | 1093 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 198 cm |
About this model
Avion completes the Author Avion model. There are 5 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Hybrid bikes average weight
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 11.8 kg (26.01 lbs), Author bike is much lighter than average. To sum up, it’s 17.37% lighter than the average weight of Hybrid bikes.
Overview of components
Fork
The fork installed on this bike is the RST VOGUE model. The travel on this model is 60mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Avion 2015 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Avion comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 198 cm (4.92 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
