Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
150cm - 166cm
18"
164cm - 176cm
20"
174cm - 186cm
22"
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR carbon Toray T700/800 monocoque 29"
Suspension Fork
AUTHOR carbon 1.5" tapered
Drivetrain
Rear Derailleur
SHIMANO GRX 400
Front Derailleur
SHIMANO GRX 400 (34.9)
Shift Levers
SHIMANO Tiagra (20)
Cassette
SHIMANO HG500-10, 11-34 (10)
Crank
SHIMANO GRX 600, 46-30 teeth, 170 / 175 mm cranks
Chain
KMC X10
Wheels
Front Hub
AUTHOR Helium / Xenon, 15 × 100 mm thru front axle, 12 × 142 mm thru rear axle, 32 holes
Rear Hub
AUTHOR Helium / Xenon, 15 × 100 mm thru front axle, 12 × 142 mm thru rear axle, 32 holes
Rims
AUTHOR Xenon 29, 32 holes
Spokes
black stainless steel 2.0 mm
Tires
PANARACER Gravel King SK aramid 700 × 43c
Brakes
Brakes
SHIMANO Deore, disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm, 660 / 680 mm
Grips
AUTHOR Microtech ErgoGrip
Seat
Saddle
AUTHOR Navigator CR
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.63 mm | 1.62 mm | 1.57 mm |
| Front Center | 612 mm | 633 mm | 654 mm | 674 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 74 mm | 74 mm | 74 mm | 74 mm |
| Stack | 620 mm | 639 mm | 658 mm | 667 mm |
| Reach | 378 mm | 392 mm | 407 mm | 424 mm |
| Top Tube Length | 566 mm | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 160 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1061 mm | 1082 mm | 1103 mm | 1123 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 200 cm |
About this model
Avion is part of the Author Avion model. Author launched 5 bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Hybrid bikes average weight
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.99 kg (30.84 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
much lighter than average, Avion has a weight of 10 kg (22.05 lbs). To sum up, it’s 39.9% lighter than the average weight of Hybrid bikes.
Avion components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Avion 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Author Avion is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Avion comes in 4 sizes, that range from 150 cm – 200 cm (4.92 ft – 6.56 ft). In short, you can easily find one that suits you.
