Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork RST VOGUE
-
Groupset CUES -
Suspension Hardtail -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
16"
150cm - 168cm
18"
165cm - 178cm
20"
175cm - 188cm
22"
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
triple butted alloy 6061 29"
Suspension Fork
RST Vogue Air TRL, air, remote lock out (80 mm)
Drivetrain
Rear Derailleur
SHIMANO Cues 6000
Front Derailleur
SHIMANO Cues 6000 (31.8)
Shift Levers
SHIMANO Cues 6000 (22)
Cassette
SHIMANO CS-LG400-11, 11-45 (11)
Crank
SHIMANO Cues 6000, 46-30 teeth, 170 / 175 mm cranks
Chain
KMC XGlide
Pedals
AUTHOR alloy
Wheels
Front Hub
AUTHOR Xenon, 32 holes
Rear Hub
AUTHOR Xenon, 32 holes
Rims
AUTHOR Xenon 29, 32 holes
Spokes
black stainless steel 2.0 mm
Tires
AUTHOR Speed Master, aramid, 29" × 1.75"
Brakes
Brakes
TEKTRO HD-M530, disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR alloy, 15 mm, 660 / 680 / 700 mm
Seat
Saddle
AUTHOR Sphere Gel
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.638 mm | 1.628 mm | 1.614 mm | 1.606 mm |
| Front Center | 612 mm | 633 mm | 654 mm | 674 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 74 mm | 74 mm | 74 mm | 75 mm |
| Stack | 611 mm | 630 mm | 649 mm | 668 mm |
| Reach | 373 mm | 387 mm | 402 mm | 416 mm |
| Top Tube Length | 560 mm | 580 mm | 600 mm | 620 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1055 mm | 1076 mm | 1097 mm | 1117 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 168 cm | 178 cm | 188 cm | 200 cm |
