Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork RST VIV AIR
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery SHIMANO E-8010 Li-Ion, 36 V, 14 Ah, 504 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
150cm - 168cm
18"
165cm - 178cm
20"
175cm - 188cm
22"
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted hydroformed alloy 6061 29"
Suspension Fork
RST ViV Air TnL air, lock out (80 mm)
Drivetrain
Rear Derailleur
SHIMANO Alivio
Shift Levers
SHIMANO Alivio (9)
Cassette
SHIMANO HG200-9 11-36 (9)
Crank
SHIMANO Steps E-5010 38 teeth 170 / 175 mm cranks
Bottom Bracket
STEPS, press-fit
Chain
KMC e9T
Pedals
HT platform
Wheels
Front Hub
AUTHOR Radon 32 holes
Rear Hub
AUTHOR Radon 32 holes
Rims
AUTHOR Xenon 29 32 holes
Spokes
black stainless steel 2.2 mm
Tires
VITTORIA Barzo 29" × 2.10"
Brakes
Brakes
TEKTRO Gemini disc hydraulic (7" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 700 / 720 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
AUTHOR Sphere Gel
Seatpost
AUTHOR alloy (27.2)
Motor & Battery
Motor
SHIMANO Steps E-5000, 250 W
Battery
SHIMANO E-8010 Li-Ion, 36 V, 14 Ah, 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 613 mm | 634 mm | 653 mm | 674 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Top Tube Length | 566 mm | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 160 mm |
| Chainstay Length | 495 mm | 495 mm | 495 mm | 495 mm |
| Wheelbase | 1101 mm | 1122 mm | 1142 mm | 1163 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 168 cm | 178 cm | 188 cm | 200 cm |
Model Overview
Edict completes the Author E Edict model. 3 e-bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid e-bikes
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Hybrid e-bikes average weight
The average weight for Hybrid e-bikes is 23.79 kg (52.45 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 20.7 kg (45.64 lbs), the Edict model is considerably lighter than average. In short, the average Hybrid e-bike weight is 14.93% higher than this one.
Overview of components
Fork
The fork installed on this bike is the RST VIV AIR model. The travel on this model is 80mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the Edict e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 200 cm (4.92 ft – 6.56 ft). In short, you can easily find one that suits you.
