Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Suntour -
Suspension Hardtail -
Motor 250W hub-drive -
Battery PHYLION Li-lon, 36V, 11,6 Ah, 418 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c (L)
Suspension Fork
SUNTOUR NEX-E25 (63 mm)
Drivetrain
Rear Derailleur
SHIMANO Alivio
Shift Levers
SHIMANO Alivio (9)
Cassette
SHIMANO HG-300-9, 11-34 teeth, 9 speed
Crank
SUNTOUR EBCW, 42 teeth, 170mm cranks
Chain
KMC X9e
Pedals
AUTHOR Non Slip alloy
Wheels
Front Hub
AUTHOR Radon 36 holes, SUNTOUR 36 holes
Rear Hub
AUTHOR Radon 36 holes, SUNTOUR 36 holes
Rims
AUTHOR Radon Cross 36 holes
Spokes
black stainless steel 2.0mm
Tires
CST reflexive stripes 700 x 40c
Brakes
Brakes
TEKTRO Vela disc hydraulic (6" rotors)
Cockpit
Stem
UNO adjustable
Handlebar
AUTHOR 25mm/ 640 mm
Grips
AUTHOR ErgoGrip
Seat
Saddle
AUTHOR Queen Sofa
Seatpost
UNO suspension (27.2)
Motor & Battery
Motor
SUNTOUR 250W
Battery
PHYLION Li-lon, 36V, 11,6 Ah, 418 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 641 mm | 673 mm |
| Rake | 46 mm | 46 mm |
| Top Tube Length | 534 mm | 566 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 160 mm |
| Chainstay Length | 457 mm | 457 mm |
| Wheelbase | 1093 mm | 1125 mm |
| Bottom Bracket Drop | 50 mm | 50 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
About this model
Electra is an Author E Electra model. Author released 7 e-bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Commuter e-bikes average weight
On a deeper look, we notice that the average weight of a Commuter e-bike is 25.2 kg (55.56 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 23.6 kg (52.03 lbs), Author e-bike is a bit lighter than average. In other words, this model is 6.78% lighter than the average Commuter e-bike.
Overview of components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Author Electra 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Author Electra is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Electra comes in 2 sizes, that range from 155 cm – 182 cm (5.09 ft – 5.97 ft). In short, you can easily find one that suits you.
