Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Suntour -
Suspension Hardtail -
Motor 250W hub-drive -
Battery PHYLION Li-lon, 36V, 11,6 Ah, 418 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c (L)
Suspension Fork
SUNTOUR NEX-E25 (63 mm)
Drivetrain
Rear Derailleur
SHIMANO Alivio
Shift Levers
SHIMANO Alivio (9)
Cassette
SHIMANO HG-300-9, 11-34 teeth, 9 speed
Crank
SUNTOUR EBCW, 42 teeth, 170mm cranks
Chain
KMC X9e
Pedals
AUTHOR Non Slip alloy
Wheels
Front Hub
AUTHOR Radon 36 holes, SUNTOUR 36 holes
Rear Hub
AUTHOR Radon 36 holes, SUNTOUR 36 holes
Rims
AUTHOR Radon Cross 36 holes
Spokes
black stainless steel 2.0mm
Tires
CST reflexive stripes 700 x 40c
Brakes
Brakes
TEKTRO Vela disc hydraulic (6" rotors)
Cockpit
Stem
UNO adjustable
Handlebar
AUTHOR 25mm/ 640 mm
Grips
AUTHOR ErgoGrip
Seat
Saddle
AUTHOR Queen Sofa
Seatpost
UNO suspension (27.2)
Motor & Battery
Motor
SUNTOUR 250W
Battery
PHYLION Li-lon, 36V, 11,6 Ah, 418 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 641 mm | 673 mm |
| Rake | 46 mm | 46 mm |
| Top Tube Length | 534 mm | 566 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 160 mm |
| Chainstay Length | 457 mm | 457 mm |
| Wheelbase | 1093 mm | 1125 mm |
| Bottom Bracket Drop | 50 mm | 50 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
About this model
Electra is part of the Author E Electra model. Author launched 7 e-bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter e-bikes average price
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Commuter e-bikes average weight
Commuter e-bikes have an average weight of 25.2 kg (55.56 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Author Electra it’s weighing 23.6 kg (52.03 lbs). At this weight, is a bit lighter than average. To sum up, it’s 6.78% lighter than the average weight of Commuter e-bikes.
Electra components
Fork
This e-bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The Electra 2018 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Electra comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Author Electra e-bike has 2 sizes, in the range of 155 cm – 182 cm (5.09 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
