Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NOVA
-
Groupset Alivio -
Suspension Hardtail -
Motor Bafang 250W hub-drive -
Battery HAN-WIN Li-lon, 36V, 14 Ah, 522 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c (L)
Suspension Fork
RST Nova TnL lock out(60 mm)
Drivetrain
Rear Derailleur
SHIMANO Alivio
Shift Levers
SHIMANO Alivio (9)
Cassette
SHIMANO HG400-9 11-34 (9)
Crank
BAFANG 38 teeth 170 mm cranks
Chain
KMC e9T
Pedals
AUTHOR Non Slip alloy
Wheels
Front Hub
AUTHOR Radon 36 holes
Rear Hub
AUTHOR Radon 36 holes
Rims
AUTHOR Radon Cross 36 holes
Spokes
black stainless steel 2.0 mm
Tires
CST reflexive stripes 700 x 40c
Brakes
Brakes
TEKTRO Vela disc hydraulic (6" rotors)
Cockpit
Stem
UNO adjustable
Handlebar
AUTHOR 25 mm 640 mm
Grips
AUTHOR Microtech ErgoGrip
Seat
Saddle
AUTHOR Queen Sofa
Seatpost
UNO suspension (27.2)
Motor & Battery
Motor
BAFANG Max Motor 250W
Battery
HAN-WIN Li-lon, 36V, 14 Ah, 522 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 641 mm | 673 mm |
| Rake | 46 mm | 46 mm |
| Top Tube Length | 534 mm | 566 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 160 mm |
| Chainstay Length | 457 mm | 457 mm |
| Wheelbase | 1093 mm | 1125 mm |
| Bottom Bracket Drop | 50 mm | 50 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
Model Overview
Electra belongs to the Author E Electra model. Author launched 7 e-bikes of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter e-bikes average price
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Average weight for Commuter e-bikes
Commuter e-bikes have an average weight of 25.2 kg (55.56 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 24.3 kg (53.57 lbs), the Electra model is slightly lighter than average. In short, the average Commuter e-bike weight is 3.7% higher than this one.
Electra components
Fork
This e-bike has the RST NOVA fork installed. The fork’s travel is 60mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Electra 2019 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Electra comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Electra comes in 2 sizes, that range from 155 cm – 182 cm (5.09 ft – 5.97 ft). In conclusion, you won’t have a problem finding one that suits you.
