Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NOVA
-
Groupset Alivio -
Suspension Hardtail -
Motor Bafang 250W hub-drive -
Battery Han-Win, 36 V, 14 Ah, 500 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c (L)
Suspension Fork
RST Nova TnL lock out (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Alivio
Shift Levers
SHIMANO Alivio (9)
Cassette
SHIMANO HG400-9 11-34 (9)
Crank
BAFANG 38 teeth 170 mm cranks
Chain
KMC e9T
Pedals
AUTHOR Non Slip alloy
Wheels
Front Hub
AUTHOR Radon 36 holes
Rear Hub
AUTHOR Radon 36 holes
Rims
AUTHOR Radon Cross 36 holes
Spokes
stainless steel hi-ten 2.0 mm black
Tires
CST reflexní pruhy 700 × 40c
Brakes
Brakes
TEKTRO Vela disc hydraulic (6" rotors)
Cockpit
Stem
UNO adjustable
Handlebar
AUTHOR 25 mm 640 mm
Grips
AUTHOR Microtech ErgoGrip
Seat
Saddle
AUTHOR Queen Sofa
Seatpost
UNO suspension (27.2)
Motor & Battery
Motor
BAFANG Max Motor 250 W
Battery
Han-Win, 36 V, 14 Ah, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 651 mm | 673 mm |
| Top Tube Length | 544 mm | 566 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 160 mm |
| Chainstay Length | 477 mm | 457 mm |
| Wheelbase | 1123 mm | 1125 mm |
| Bottom Bracket Drop | 50 mm | 50 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
Model Overview
Electra belongs to the Author E Electra model. 7 e-bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter e-bikes
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Commuter e-bikes
If we make a quick analysis of the average weight of a Commuter e-bike, we get 25.2 kg (55.56 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 23.8 kg (52.47 lbs), Author e-bike is a bit lighter than average. To sum up, it’s 5.88% lighter than the average weight of Commuter e-bikes.
Electra components
Fork
The fork installed on this bike is the RST NOVA model. The travel on this model is 60mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Electra e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Electra has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Electra comes in 2 sizes, that range from 155 cm – 182 cm (5.09 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
