Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RST F1RST
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 50Nm mid-drive -
Battery SHIMANO BT-E8010 Li-lon, 36V, 14 Ah, 500 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
168cm - 180cm
19"
177cm - 190cm
21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted hydroformed alloy 6061 29"
Suspension Fork
RST F1RST 29 15 TRL air, remote lock out 15 mm thru axle (100 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Shift Levers
SHIMANO Deore (10)
Cassette
SHIMANO HG50-10 11-36 (10)
Crank
SHIMANO Steps E6000 38 teeth 170 / 175 mm cranks
Bottom Bracket
STEPS, press-fit
Chain
KMC e10T
Pedals
HT platmorm
Wheels
Front Hub
AUTHOR Helium 15 / Xenon 12 15 x 100 mm thru front axle 12 x 142 mm thru rear axle 32 holes
Rear Hub
AUTHOR Helium 15 / Xenon 12 15 x 100 mm thru front axle 12 x 142 mm thru rear axle 32 holes
Rims
AUTHOR E-Krypton 29 32 holes
Spokes
black stainless steel 2.2 mm
Tires
VITTORIA e-Barzo kevlar 29" x 2.25"
Brakes
Brakes
TRP Slate 4 disc hydraulic (7" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 700 / 720 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
AUTHOR Navigator
Seatpost
AUTHOR alloy (30.9)
Motor & Battery
Motor
SHIMANO Steps DU-E6002, 250W
Battery
SHIMANO BT-E8010 Li-lon, 36V, 14 Ah, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.49 mm | 1.44 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 696 mm | 717 mm | 737 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 96 mm | 96 mm | 96 mm |
| Stack | 624 mm | 633 mm | 638 mm |
| Reach | 407 mm | 424 mm | 442 mm |
| Top Tube Length | 598 mm | 618 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 135 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm |
| Wheelbase | 1168 mm | 1189 mm | 1209 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 187 cm |
| Rider Max Height | 180 cm | 190 cm | 202 cm |
Model Overview
Elevation 29 is an Author E Elevation model. There are 7 e-bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry e-bikes
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry e-bikes average weight
The average weight for Crosscountry e-bikes is 23.21 kg (51.17 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Elevation 29 weighs 20.8 kg (45.86 lbs) and is considerably lighter than the average. In other words, this model is 11.59% lighter than the average Crosscountry e-bike.
Elevation 29 components
Fork
The Elevation 29 comes factory-installed with the RST F1RST fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Elevation 29 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Elevation 29 comes in 3 sizes, that range from 168 cm – 202 cm (5.51 ft – 6.63 ft). In short, it won’t be difficult to find the right one for you.
