Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Rhythm Float 34
-
Groupset CUES, Shimano -
Suspension Full -
Motor Shimano 250W mid-drive -
Battery SHIMANO E-806 Li-Ion, 36 V, 17,5 Ah, 630 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
160cm - 171cm
18"
169cm - 181cm
20"
179cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloyl 6061 29" suspension (integrated battery), air shock FOX DPS Perfomance Float 205 / 57.5 mm (rear travel 150 mm)
Suspension Fork
FOX 34 Rhythm Float, air, lock out, 15 mm thru axle, 1.5" tapered steerer (150 mm)
Drivetrain
Rear Derailleur
SHIMANO Cues 6000
Shift Levers
SHIMANO Cues 6000 (11)
Cassette
SHIMANO CS-LG400-11, 11-50 (11)
Crank
SHIMANO Steps E-M600, 38 teeth, 170 / 175 mm cranks
Bottom Bracket
STEPS, press-fit
Chain
KMC eGlide
Pedals
HT platform
Wheels
Front Hub
QUANDO, 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
Rear Hub
QUANDO, 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
Rims
AUTHOR E-Krypton 29, 32 holes
Spokes
black stainless steel 2.2 mm
Tires
MAXXIS Dissector aramid 29" × 2.60"
Brakes
Brakes
TRP Slate EVO, 4-piston disc hydraulic (7" rotors)
Cockpit
Stem
RITCHEY MTN Trail
Handlebar
RITCHEY MTN Rizer Trail WCS, 15 mm, 760 / 780 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
AUTHOR E-Mode
Seatpost
KIND SHOCK RAGEi, suspension, travel 125 mm / 150 mm (30.9)
Motor & Battery
Motor
SHIMANO Steps E-P801, 250 W
Battery
SHIMANO E-806 Li-Ion, 36 V, 17,5 Ah, 630 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" |
|---|---|---|---|
| Stack Reach Ratio | 1.488 mm | 1.437 mm | 1.361 mm |
| Bottom Bracket Height | 359 mm | 359 mm | 359 mm |
| Front Center | 746 mm | 761 mm | 792 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 115 mm | 115 mm | 114 mm |
| Stack | 628 mm | 628 mm | 633 mm |
| Reach | 422 mm | 437 mm | 465 mm |
| Top Tube Length | 590 mm | 605 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 130 mm | 130 mm | 130 mm |
| Chainstay Length | 469 mm | 469 mm | 469 mm |
| Wheelbase | 1215 mm | 1230 mm | 1261 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm |
| Rider Max Height | 171 cm | 181 cm | 190 cm |
