Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NEON
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c (L)
Suspension Fork
RST Neon ML lock out (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Acera
Front Derailleur
SHIMANO TX50 (31.8)
Shift Levers
SHIMANO Acera (24)
Cassette
SHIMANO HG31-8 11-32 (8)
Crank
SUNTOUR XCE 42-34-24 teeth 170 cranks
Chain
KMC Z72
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO 32 holes
Rear Hub
QUANDO 32 holes
Rims
AUTHOR Argon Cross 32 holes
Spokes
black steel
Tires
AUTHOR Speed Master 700 x 42c
Brakes
Brakes
TEKTRO 855
Cockpit
Stem
ZOOM adjustable
Handlebar
steel 20 mm 640 mm
Grips
AUTHOR high density foam
Seat
Saddle
AUTHOR Noble
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 630 mm | 650 |
| Rake | 44 mm | 44 mm |
| Top Tube Length | 563 mm | 583 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 150 mm |
| Chainstay Length | 438 mm | 438 mm |
| Wheelbase | 1061 mm | 1081 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
About this model
Integra completes the Author Integra model. Author launched 9 bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Hybrid bikes average weight
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 13.4 kg (29.54 lbs), the Integra model is slightly lighter than average. To sum up, it’s 3.36% lighter than the average weight of Hybrid bikes.
Integra components
Fork
The RST NEON is included from the factory. It has a travel distance of 60mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Author Integra 2016, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Author Integra has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 2 sizes. They vary from 155 cm – 182 cm (5.09 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
