Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NEON
-
Groupset Altus, Suntour -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c (L)
Suspension Fork
RST Neon ML lock out (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Altus
Front Derailleur
SHIMANO Altus (31.8)
Shift Levers
SHIMANO Altus (27)
Cassette
SHIMANO HG200-9 11-34 (9)
Crank
SUNTOUR NCX 44-32-22 teeth 170 mm cranks
Chain
KMC Z99
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO 32 holes
Rear Hub
QUANDO 32 holes
Rims
AUTHOR Argon Cross 32 holes
Spokes
black steel
Tires
AUTHOR Speed Master 700 x 42c
Brakes
Brakes
TEKTRO V
Cockpit
Stem
ZOOM adjustable
Handlebar
steel 20 mm 640 mm
Grips
AUTHOR ErgoGrip
Seat
Saddle
AUTHOR Noble
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 630 mm | 650 |
| Rake | 44 mm | 44 mm |
| Top Tube Length | 563 mm | 583 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 150 mm |
| Chainstay Length | 438 mm | 438 mm |
| Wheelbase | 1061 mm | 1081 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
Model Overview
Integra completes the Author Integra model. There are 9 bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Hybrid bikes
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Author Integra it’s weighing 13.6 kg (29.98 lbs). At this weight, is slightly lighter than average. In short, the average Hybrid bike weight is 1.84% higher than this one.
Integra components
Fork
This bike has the RST NEON fork installed. The fork’s travel is 60mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Integra 2018 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Author Integra bike has 2 sizes, in the range of 155 cm – 182 cm (5.09 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
