Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork RST CAPA
-
Groupset Altus, Suntour -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 29" (L)
Suspension Fork
RST Capa 29 ML lock out (80 mm)
Drivetrain
Rear Derailleur
SHIMANO Altus
Front Derailleur
SHIMANO Altus (31.8)
Shift Levers
SHIMANO Altus (27)
Cassette
SHIMANO HG200-9 11-34 (9)
Crank
SUNTOUR NCX 44-32-22 teeth 170 mm cranks
Chain
KMC Z9
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO 32 holes
Rear Hub
QUANDO 32 holes
Rims
AUTHOR Argon 29 32 holes
Spokes
black steel
Tires
AUTHOR Speed Master 29"x 1.75"
Brakes
Brakes
TEKTRO V
Cockpit
Stem
ZOOM adjustable
Handlebar
steel 20 mm 640 mm
Grips
AUTHOR ErgoGrip
Seat
Saddle
AUTHOR Noble
Seatpost
ZOOM alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 637 mm | 657 mm |
| Rake | 51 mm | 51 mm |
| Top Tube Length | 563 mm | 583 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 130 mm |
| Chainstay Length | 448 mm | 448 mm |
| Wheelbase | 1078 mm | 1098 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
Model Overview
Integra completes the Author Integra model. Author launched 9 bikes of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Hybrid bikes average weight
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 14.1 kg (31.09 lbs), the Integra model is slightly heavier than average. To sum up, it’s 1.81% heavier than the average weight of Hybrid bikes.
Integra components
Fork
The Integra comes factory-installed with the RST CAPA fork. This has a travel range of 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Author Integra 2019, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Integra comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Integra comes in 2 sizes, that range from 155 cm – 182 cm (5.09 ft – 5.97 ft). In conclusion, you won’t have a problem finding one that suits you.
