Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NEON
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
17"
155cm - 169cm
19"
167cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 (L)
Suspension Fork
RST Neon ML, lock out (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Alivio
Front Derailleur
SHIMANO Altus (31.8)
Shift Levers
SHIMANO Acera (27)
Cassette
SHIMANO HG200-9, 11-34 (9)
Crank
PROWHEEL Burner, 44-32-22 teeth, 170 / 175 mm cranks
Chain
KMC Z9
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO, 32 holes
Rear Hub
QUANDO, 32 holes
Rims
AUTHOR Argon 29, 32 holes
Spokes
black steel
Tires
AUTHOR Cross 700 × 38c
Brakes
Brakes
TEKTRO V
Cockpit
Stem
ZOOM adjustable
Handlebar
steel, 20 mm, 640 mm
Grips
AUTHOR ErgoGrip
Seat
Saddle
AUTHOR Noble
Seatpost
ZOOM alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 637 mm | 657 mm |
| Rake | 51 mm | 51 mm |
| Top Tube Length | 565 mm | 585 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 150 mm |
| Chainstay Length | 440 mm | 440 mm |
| Wheelbase | 1070 mm | 1090 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 155 cm | 167 cm |
| Rider Max Height | 169 cm | 182 cm |
About this model
Integra completes the Author Integra model. 10 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Hybrid bikes average weight
The average weight for Hybrid bikes is 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Author Integra it’s weighing 13.5 kg (29.76 lbs). At this weight, is slightly lighter than average. In other words, this model is 2.59% lighter than the average Hybrid bike.
Integra components
Fork
The RST NEON is included from the factory. It has a travel distance of 60mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on Integra are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Author Integra has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Integra comes in 2 sizes, that range from 155 cm – 182 cm (5.09 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
