Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RST BLAZE
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
15"
145cm - 158cm
29"/17"
168cm - 180cm
29"/19"
177cm - 190cm
29"/21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 27.5" / 29"
Suspension Fork
RST Blaze 27.5 / 29 TnL, lock out (100 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Shift Levers
SHIMANO Deore (12)
Cassette
SHIMANO CS-M6100-12, 10-51 (12)
Crank
SHIMANO M510-1, 34 teeth, 170 / 175 mm cranks
Chain
KMC X12
Pedals
AUTHOR alloy
Wheels
Front Hub
QUANDO Disc / SHIMANO, 32 holes
Rear Hub
QUANDO Disc / SHIMANO, 32 holes
Rims
AUTHOR Xenon TRC 27.5/29, 32 holes
Spokes
black steel
Tires
AUTHOR Rocket 27.5" × 2.10" / VITTORIA Barzo 29" × 2.10"
Brakes
Brakes
TEKTRO HD-M280, disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR rise 25 mm, 9°, 660 mm / AUTHOR Flatbar, 10°, 680 / 700 mm
Seat
Saddle
AUTHOR Navigator
Seatpost
AUTHOR alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 29"/17" | 29"/19" | 29"/21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.616 mm | 1.469 mm | 1.422 mm | 1.412 mm |
| Bottom Bracket Height | 339 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 617 mm | 693 mm | 719 mm | 741 mm |
| Rake | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 108 mm | 89 mm | 88 mm | 89 mm |
| Stack | 593 mm | 620 mm | 630 mm | 648 mm |
| Reach | 367 mm | 422 mm | 443 mm | 459 mm |
| Top Tube Length | 570 mm | 600 mm | 625 mm | 645 mm |
| Seat Tube Angle | 73 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 535 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 435 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1050 mm | 1135 mm | 1161 mm | 1183 mm |
| Bottom Bracket Drop | 35 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 145 cm | 168 cm | 177 cm | 187 cm |
| Rider Max Height | 158 cm | 180 cm | 190 cm | 202 cm |
