Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Tektro Rim
Sizing
Recommended size guide.
13"
130cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 26"
Suspension Fork
alloy 6061 26"
Drivetrain
Rear Derailleur
SHIMANO TX800
Shift Levers
SHIMANO Altus (8)
Cassette
SHIMANO CS-HG31-8, 11-34 (8)
Crank
PROWHEEL, 32 teeth, 152 mm cranks
Chain
KMC Z8.3
Pedals
plastic
Wheels
Front Hub
QUANDO, 32 holes
Rear Hub
QUANDO, 32 holes
Rims
alloy, 32 holes
Spokes
steel
Tires
KENDA Small Block Eight, 26" × 1.95"
Brakes
Brakes
TEKTRO V
Cockpit
Stem
alloy
Handlebar
steel, 20 mm, 620 mm
Seat
Saddle
AUTHOR
Seatpost
alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" |
|---|---|
| Stack Reach Ratio | 1.412 mm |
| Front Center | 584 mm |
| Rake | 45 mm |
| Stack | 524 mm |
| Reach | 371 mm |
| Top Tube Length | 526 mm |
| Seat Tube Angle | 73.5 ° |
| Seat Tube Length | 343 mm |
| Head Tube Angle | 69.5 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 425 mm |
| Wheelbase | 1007 mm |
| Bottom Bracket Drop | 30 mm |
| Wheels | 26" |
| Rider Min Height | 130 cm |
| Rider Max Height | 150 cm |
