Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Acera -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Tektro Rim
Sizing
Recommended size guide.
14"
140cm - 158cm
16"
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 27.5"
Suspension Fork
alloy 6061 27.5"
Drivetrain
Rear Derailleur
SHIMANO Acera
Shift Levers
SHIMANO Acera (8)
Cassette
SHIMANO CS-HG400-8, 11-40 (8)
Crank
PROWHEEL, 32 teeth, 165 / 170 mm cranks
Chain
KMC Z8.3
Pedals
plastic
Wheels
Front Hub
QUANDO, 32 holes
Rear Hub
QUANDO, 32 holes
Rims
alloy, 32 holes
Spokes
black steel
Tires
KENDA Small Block Eight, 27.5" × 2.10"
Brakes
Brakes
TEKTRO V
Cockpit
Stem
alloy
Handlebar
steel, 20 mm, 640 mm
Seat
Saddle
AUTHOR
Seatpost
alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" |
|---|---|---|
| Stack Reach Ratio | 1.332 mm | 1.293 mm |
| Front Center | 634 mm | 649 mm |
| Rake | 45 mm | 45 mm |
| Stack | 530 mm | 538 mm |
| Reach | 398 mm | 416 mm |
| Top Tube Length | 550 mm | 575 mm |
| Seat Tube Angle | 74 ° | 73.5 ° |
| Seat Tube Length | 356 mm | 406 mm |
| Head Tube Angle | 69 ° | 69.5 ° |
| Head Tube Length | 110 mm | 115 mm |
| Chainstay Length | 420 mm | 420 mm |
| Wheelbase | 1050 mm | 1065 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 140 cm | 155 cm |
| Rider Max Height | 158 cm | 170 cm |
