Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Acera -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
14"
143cm - 160cm
16"
157cm - 173cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 29"
Suspension Fork
alloy 6061 29"
Drivetrain
Rear Derailleur
SHIMANO Acera
Shift Levers
SHIMANO Acera (8)
Cassette
SHIMANO CS-HG400-8, 11-40 (8)
Crank
PROWHEEL, 32 teeth, 165 / 170 mm cranks
Chain
KMC Z8.3
Pedals
plastic
Wheels
Front Hub
QUANDO, 32 holes
Rear Hub
QUANDO, 32 holes
Rims
alloy, 32 holes
Spokes
black steel
Tires
KENDA Small Block Eight, 29" × 2.10"
Brakes
Brakes
TEKTRO HD-M276, disc hydraulic (6" rotors)
Cockpit
Stem
alloy
Handlebar
steel, 20 mm, 660 mm
Seat
Saddle
AUTHOR
Seatpost
alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" |
|---|---|---|
| Stack Reach Ratio | 1.411 mm | 1.366 mm |
| Front Center | 623 mm | 647 mm |
| Rake | 45 mm | 45 mm |
| Stack | 546 mm | 556 mm |
| Reach | 387 mm | 407 mm |
| Top Tube Length | 544 mm | 566 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 356 mm | 406 mm |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 90 mm | 100 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1060 mm | 1084 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 143 cm | 157 cm |
| Rider Max Height | 160 cm | 173 cm |
