Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset XT, SLX -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
171cm - 181cm
19"
179cm - 190cm
21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR carbon Toray T700/800 monocoque 29"
Suspension Fork
ROCK SHOX Recon Gold RL Remote 29 15 Solo Air air, remote lock out 15 × 110 mm thru axle, 1.5" tapered steerer (100 mm)
Drivetrain
Rear Derailleur
SHIMANO XT
Shift Levers
SHIMANO SLX (12)
Cassette
SHIMANO CS-M7100 10-51 (12)
Crank
SHIMANO SLX 34 teeth 170 / 175 mm cranks
Chain
SHIMANO M7100
Wheels
Front Hub
AUTHOR / SHIMANO SLX 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
Rear Hub
AUTHOR / SHIMANO SLX 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
Rims
AUTHOR Krypton TRC 29 32 holes
Spokes
black stainless steel 2.0 mm
Tires
VITTORIA Barzo foldable 29" × 2.25"
Brakes
Brakes
SHIMANO Deore disc hydraulic (7" rotors)
Cockpit
Stem
RITCHEY Comp 4-Axis
Handlebar
RITCHEY MTN Comp 2×9 9° 700 / 720 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
PROLOGO Nago Evo X10
Seatpost
RITCHEY Comp (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm |
| Front Center | 691 mm | 718 mm | 750 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 90 mm | 89 mm | 89 mm |
| Stack | 610 mm | 614 mm | 633 mm |
| Reach | 426 mm | 451 mm | 476 mm |
| Top Tube Length | 612 mm | 639 mm | 669 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 435 mm | 485 mm | 535 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1119 mm | 1146 mm | 1178 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 181 cm | 190 cm | 202 cm |
Model Overview
Master 29 completes the Author Master model. Author launched 4 bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 11.2 kg (24.69 lbs), the Master 29 model is considerably lighter than average. In other words, this model is 10.71% lighter than the average Crosscountry bike.
Overview of components
Fork
Author Master 29 2022 bike is equipped with the RockShox Recon Gold RL fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the Master 29 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Master 29 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Master 29 comes in 3 sizes, that range from 171 cm – 202 cm (5.61 ft – 6.63 ft). In conclusion, it won’t take much to find one that’s right for you.
