Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork RST CAPA
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
15"
145cm - 165cm
17"
155cm - 172cm
19"
170cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 26"
Suspension Fork
RST Capa 26 T (80 mm)
Drivetrain
Rear Derailleur
SHIMANO TY500
Front Derailleur
SHIMANO TY500 (34.9)
Shift Levers
SHIMANO (21)
Cassette
SHIMANO MF-TZ510 14-34 (7)
Crank
PROWHEEL 42-34-24 teeth 170 mm cranks
Chain
KMC Z7
Pedals
resin
Wheels
Front Hub
QUANDO 36 holes
Rear Hub
QUANDO 36 holes
Rims
alloy 36 holes
Spokes
steel
Tires
AUTHOR Rocket 26" × 2.10"
Brakes
Brakes
TEKTRO V
Cockpit
Stem
ZOOM alloy
Handlebar
steel 20 mm 640 mm
Grips
AUTHOR high density foam
Seat
Saddle
AUTHOR
Seatpost
alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.42 mm | 1.35 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm |
| Front Center | 625 mm | 656 mm | 681 mm |
| Rake | 68 mm | 68 mm | 68 mm |
| Trail | 93 mm | 88 mm | 89 mm |
| Stack | 573 mm | 578 mm | 582 mm |
| Reach | 382 mm | 406 mm | 430 mm |
| Top Tube Length | 558 mm | 583 mm | 608 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 130 mm | 135 mm | 140 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1042 mm | 1073 mm | 1098 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 145 cm | 155 cm | 170 cm |
| Rider Max Height | 165 cm | 172 cm | 185 cm |
About this model
Outset 26 is part of the Author Outset model. 3 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 13.6 kg (29.98 lbs), the Outset 26 model is a bit heavier than average. In short, the average Crosscountry bike weight is 9.68% lower than this one.
Overview of components
Fork
Author Outset 26 2022 bike is equipped with the RST CAPA fork, and has 80mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the Outset 26 bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 145 cm – 185 cm (4.76 ft – 6.07 ft). In short, you can easily find one that suits you.
