Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Float 32
-
Groupset XT -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
168cm - 180cm
19"
177cm - 190cm
21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR B-carbon monocoque 29"
Suspension Fork
FOX 32 Float 29 CTD O/C 100 air, remote lock out 15 mm thru axle 1.5" tapered steerer (100 mm)
Drivetrain
Rear Derailleur
SHIMANO XT
Front Derailleur
SHIMANO XT (34.9)
Shift Levers
SHIMANO XT (30)
Cassette
SHIMANO M771-10 11-36 (10)
Crank
SHIMANO XT 40-30-22 teeth 170 / 175 mm cranks
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO HG-75
Pedals
SHIMANO M540 clipless
Wheels
Front Hub
SHIMANO XT Disc 15 mm thru axle 32 holes
Rear Hub
SHIMANO XT Disc 15 mm thru axle 32 holes
Rims
AUTHOR Helium Pro 29 white 32 holes
Spokes
black stainless steel 2.0 mm
Tires
GEAX Mezcal Kevlar 29" x 2.10"
Brakes
Brakes
SHIMANO XT disc hydraulic (7" rotors)
Cockpit
Stem
EASTON EA90
Handlebar
EASTON EA70 XC 0 mm 720 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
FIZIK Gobi XM
Seatpost
EASTON EA70 Zero (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 668 mm | 686 mm | 702 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 604 mm | 628 mm | 649 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 432 mm | 482 mm | 535 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1110 mm | 1128 mm | 1144 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 187 cm |
| Rider Max Height | 180 cm | 190 cm | 202 cm |
Model Overview
Sector 29 is part of the Author Sector model. Author released 9 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Sector 29 components
Fork
This bike has the Fox Float 32 fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The Sector 29 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sector 29 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 168 cm – 202 cm (5.51 ft – 6.63 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Sector 29. Therefore, climbing or descending will be a breeze.
