Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Float 32
-
Groupset XT -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
168cm - 180cm
19"
177cm - 190cm
21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR B carbon monocoque 29"
Suspension Fork
FOX 32 Float 29 CTD Remote O/C 100 air, remote lock out 15 mm thru axle 1.5" tapered steerer (100 mm)
Drivetrain
Rear Derailleur
SHIMANO XT "clutch"
Front Derailleur
SHIMANO XT (34.9)
Shift Levers
SHIMANO XT (20)
Cassette
SHIMANO M771-10 11-36 (10)
Crank
SHIMANO XT 40-28 teeth 170 / 175 mm cranks
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO HG95
Pedals
SHIMANO M540 clipless
Wheels
Front Hub
SHIMANO XT Disc 15 mm thru front axle 142 x 12 mm thru rear axle 32 holes
Rear Hub
SHIMANO XT Disc 15 mm thru front axle 142 x 12 mm thru rear axle 32 holes
Rims
AUTHOR Helium Pro 29 32 holes
Spokes
black stainless steel 2.0 mm
Tires
VITTORIA Mezcal kevlar 29" x 2.10"
Brakes
Brakes
SHIMANO XT disc hydraulic (6" rotors)
Cockpit
Stem
RITCHEY WCS 4-Axis
Handlebar
RITCHEY WCS Flat 0 mm 660 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
FIZIK Gobi XM
Seatpost
AUTHOR carbon (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 668 mm | 686 mm | 702 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 604 mm | 628 mm | 649 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 432 mm | 482 mm | 535 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1110 mm | 1128 mm | 1144 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 187 cm |
| Rider Max Height | 180 cm | 190 cm | 202 cm |
Model Overview
Sector 29 is part of the Author Sector model. Author released 9 bikes variations of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Sector 29 weighs 11.1 kg (24.47 lbs) and is considerably lighter than the average. In other words, this model is 11.71% lighter than the average Crosscountry bike.
Sector 29 components
Fork
The Sector 29 comes factory-installed with the Fox Float 32 fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Author Sector 29 2015, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sector 29 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 168 cm – 202 cm (5.51 ft – 6.63 ft). In conclusion, it won’t take much to find one that’s right for you.
