Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
168cm - 180cm
19"
177cm - 190cm
21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AUTHOR B carbon monocoque 29"
Suspension Fork
FOX 32 Float 29 Performance air, remote lock out 15 mm thru axle 1.5" tapered steerer (100 mm)
Drivetrain
Rear Derailleur
SHIMANO XT "clutch"
Front Derailleur
SHIMANO XT (34.9)
Shift Levers
SHIMANO XT (22)
Cassette
SHIMANO XT 11-40 (11)
Crank
SHIMANO XT 38-28 teeth 170 / 175 mm cranks
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO HG600
Wheels
Front Hub
MAVIC Crossride Light 29 wheel set 24 holes 15 x 100 mm thru front axle 12 x 142 mm thru rear axle
Rear Hub
MAVIC Crossride Light 29 wheel set 24 holes 15 x 100 mm thru front axle 12 x 142 mm thru rear axle
Rims
MAVIC Crossride Light 29 wheel set 24 holes
Spokes
MAVIC
Tires
VITTORIA Barzo kevlar 29" x 2.10"
Brakes
Brakes
SHIMANO XT disc hydraulic (6" rotors)
Cockpit
Stem
RITCHEY WCS 4-Axis
Handlebar
RITCHEY WCS Flat 0 mm 660 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
AUTHOR Genius
Seatpost
RITCHEY Comp Carbon (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 668 mm | 686 mm | 702 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 604 mm | 628 mm | 649 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 432 mm | 482 mm | 535 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1110 mm | 1128 mm | 1144 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 187 cm |
| Rider Max Height | 180 cm | 190 cm | 202 cm |
About this model
Sector 29 is part of the Author Sector model. Author released 9 bikes variations of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
considerably lighter than average, Sector 29 has a weight of 11.2 kg (24.69 lbs). In conclusion, the average Crosscountry bike weighs 10.71% more than Sector 29.
Sector 29 components
Fork
The Sector 29 comes factory-installed with the Fox Performance Float 32 fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Sector 29 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sector 29 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Sector 29 comes in 3 sizes, that range from 168 cm – 202 cm (5.51 ft – 6.63 ft). In conclusion, finding one for you shouldn’t be a problem.
