Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RST AERIAL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
14"
140cm - 158cm
29"/16"
155cm - 168cm
29"/18"
166cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted hydroformed alloy 6061 27.5" / 29" (ASL)
Suspension Fork
RST Aerial 27.5 / 29 TRL, air, remote lock out (100 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Shift Levers
SHIMANO Deore (12)
Cassette
SHIMANO CS-M6100-12, 10-51 (12)
Crank
SHIMANO M510-1, 32 teeth, 170 / 175 mm cranks
Chain
KMC X12
Pedals
plastic
Wheels
Front Hub
QUANDO Disc / SHIMANO, 32 holes
Rear Hub
QUANDO Disc / SHIMANO, 32 holes
Rims
AUTHOR Xenon TRC 27.5/29, 32 holes
Spokes
black stainless steel 2.0 mm
Tires
VITTORIA Barzo, aramid, 27.5"/29" × 2.25"
Brakes
Brakes
SHIMANO BR-MT410, disc hydraulic (7" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR Flatbar, 9°, 660 / 680 / 700 mm
Seat
Saddle
AUTHOR Fenix
Seatpost
AUTHOR alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 29"/16" | 29"/18" |
|---|---|---|---|
| Stack Reach Ratio | 1.595 mm | 1.51 mm | 1.471 mm |
| Bottom Bracket Height | 329 mm | 314 mm | 314 mm |
| Front Center | 633 mm | 685 mm | 706 mm |
| Rake | 44 mm | 51 mm | 51 mm |
| Trail | 97 mm | 89 mm | 89 mm |
| Stack | 595 mm | 622 mm | 631 mm |
| Reach | 373 mm | 412 mm | 429 mm |
| Top Tube Length | 555 mm | 590 mm | 610 mm |
| Seat Tube Angle | 73 ° | 74 ° | 74 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 450 mm | 450 mm |
| Wheelbase | 1064 mm | 1128 mm | 1149 mm |
| Bottom Bracket Drop | 45 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 140 cm | 155 cm | 166 cm |
| Rider Max Height | 158 cm | 168 cm | 182 cm |
