Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
13"
130cm - 150cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
triple butted hydroformed alloy 6061 26"
Suspension Fork
alloy 6061 26"
Drivetrain
Rear Derailleur
SHIMANO Cues 6000
Shift Levers
SHIMANO Cues 6000 (10)
Cassette
SHIMANO CS-LG400-10, 11-48 (10)
Crank
PROWHEEL, 32 teeth, 152 mm cranks
Chain
KMC XGlide
Pedals
plastic
Wheels
Front Hub
AUTHOR Xenon, 32 holes
Rear Hub
AUTHOR Xenon, 32 holes
Rims
AUTHOR Argon 26, 32 holes
Spokes
black stainless steel 2.0 mm
Tires
KENDA Small Block Eight, aramid, 26" × 2.10"
Brakes
Brakes
TEKTRO HD-M276, disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR Flat Top bar, 0 mm, 600 mm
Seat
Saddle
AUTHOR Champion
Seatpost
AUTHOR alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" |
|---|---|
| Stack Reach Ratio | 1.408 mm |
| Front Center | 617 mm |
| Rake | 73 mm |
| Stack | 542 mm |
| Reach | 385 mm |
| Top Tube Length | 545 mm |
| Seat Tube Angle | 73.5 ° |
| Seat Tube Length | 343 mm |
| Head Tube Angle | 69.5 ° |
| Head Tube Length | 110 mm |
| Chainstay Length | 405 mm |
| Wheelbase | 1020 mm |
| Bottom Bracket Drop | 30 mm |
| Wheels | 26" |
| Rider Min Height | 130 cm |
| Rider Max Height | 150 cm |
