Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork RST F1RST
-
Groupset CUES -
Suspension Hardtail -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
14"
140cm - 158cm
16"
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
triple butted hydroformed alloy 6061 27.5"
Suspension Fork
RST F1RST 27.5, air, lock out (80 mm)
Drivetrain
Rear Derailleur
SHIMANO Cues 6000
Shift Levers
SHIMANO Cues 6000 (11)
Cassette
SHIMANO CS-LG400-11, 11-50 (11)
Crank
PROWHEEL, 32 teeth, 165 / 170 mm cranks
Chain
KMC XGlide
Pedals
plastic
Wheels
Front Hub
AUTHOR Xenon, 32 holes
Rear Hub
AUTHOR Xenon, 32 holes
Rims
AUTHOR Xenon TRC 27.5, 32 holes
Spokes
black stainless steel 2.0 mm
Tires
CST B-Trail, aramid, 27.5" × 2.25"
Brakes
Brakes
TEKTRO HD-M530, disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR Flat Top bar, 9°, 620 / 640 mm
Seat
Saddle
AUTHOR Champion / 14", AUTHOR Navigator / 16"
Seatpost
AUTHOR alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" |
|---|---|---|
| Stack Reach Ratio | 1.494 mm | 1.444 mm |
| Front Center | 636 mm | 651 mm |
| Rake | 43 mm | 43 mm |
| Stack | 575 mm | 582 mm |
| Reach | 385 mm | 403 mm |
| Top Tube Length | 550 mm | 575 mm |
| Seat Tube Angle | 74 ° | 73.5 ° |
| Seat Tube Length | 356 mm | 406 mm |
| Head Tube Angle | 69 ° | 69.5 ° |
| Head Tube Length | 110 mm | 115 mm |
| Chainstay Length | 420 mm | 420 mm |
| Wheelbase | 1052 mm | 1067 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 140 cm | 155 cm |
| Rider Max Height | 158 cm | 170 cm |
